The Pass Through Bevel Box was designed to save as much space inside a robot as possible.

• Description
• What's in the Box?
• Specifications
• Documentation

• On many robots, space is a premium. The Pass Through Bevel Box allows you to align your input 90° from your output. With a pass-through design in mind, any 3/8 inch hex shaft can be used as either an input or an output. This bevel box features durable bevel gears for low to high-load applications. The housing features a NeveRest mounting pattern, making for easy installation. When used with an Adapter Mount (am-5462), the Bevel Box can be mounted directly to Robits Tubes. One interesting feature of this gearbox is that it can accept up to two motors for even greater power input. Additionally, this gearbox is fully backwards compatible with both NeveRest Hex and NeveRest Orbital motors.

• Included Items:

  • 1 - 0.430 ID 21mm OD NeveRest Flanged Bushing (am-5534)
  • 1 - 3/8 (0.375) in. Hex ID 7/8 (0.875) in. OD Sealed Flanged Bearing (FR62RS-Hex) (am-4489)
  • 1 - Bevel Box Housing (am-5535)
  • 1 - 15 mm ID 21 mm OD Shielded Flanged Bearing (F6702ZZ) (am-5536)
  • 2 - 20 Tooth 1.5 Module 3/8 in. Hex Bore Steel Bevel Gear (am-4869)
  • 2 - M3-0.5 x 8 mm Socket Head Cap Screw with Thread Patch (am-1500)
  • 1 - NeveRest Spacer Mount (am-5537)
  • 4 - M3-0.5 x 12 mm Socket Head Cap Screw with Nylon Patch (am-1706)
  • 4 - 0.194 in. ID 0.375 in. OD 0.250 in. Long Nylon Spacer (am-1700)
  • 1 - 0.430 in. ID 0.500 in. OD 0.250 in. Long Aluminum Spacer (am-1698)
  • 4 - 10-32 x 0.75 in. Socket Head Cap Screw (am-1047)
  • 4 - 10-32 x 1 in. Socket Head Cap Screw (am-1056)
  • 1 - NeveRest Bevel Spacer (am-1766)
• • Input: NeveRest Orbital, NeveRest Hex, 3/8 in. Hex Shaft
  • Mounting Pattern: (8) M3 tapped holes on a 28 mm bolt circle
  • Output: 3/8 in. Hex Shaft
